High-speed Ethernet PHYs for line cards and network infrastructure
Data center, enterprise and carrier networks are moving to higher bandwidth and greater port density, placing more demands on the physical layer. Network platforms must maintain reliable connectivity across increasingly complex system architectures while supporting evolving Ethernet speeds, interfaces and deployment requirements.
The Marvell® Alaska® C series of high-speed PHYs provide the physical-layer connectivity needed to support these transitions across switching and network infrastructure. The product line helps system designers maintain signal quality, interface compatibility and operational flexibility as network bandwidth increases.
- Alaska C
- Vega
Alaska C
High-speed Ethernet PHYs
The Marvell® Alaska® C series of high-speed PHYs provides physical-layer adaptation between host and line-side Ethernet interfaces, helping designers connect different interface architectures within high-speed line cards and switching systems.
The product line supports flexible deployment across evolving Ethernet generations, with capabilities for signal integrity, error handling, security and timing integrated into select devices.
- Ethernet connectivity from 1 GbE through 800 GbE on supported devices
- 25G NRZ, 56G PAM4 and 112G PAM4 SerDes
- Retiming for high-speed Ethernet interfaces
- Gearboxing between NRZ and PAM4 signaling modes
- FEC generation, termination and regeneration
- Support for optical interfaces, passive direct attach cables and copper backplanes
- IEEE Auto-Negotiation and Link Training
- MACsec with AES-256 support
- IEEE 1588v2 precision timestamping and SyncE support
- Flexible SerDes crossbar functionality
Alaska C 9340P
Dual 800GbE retimer DSP PSM-4, gGearbox, MACsec and PTP Ethernet PHY with 100G serial I/Os at 1.6T capacity
Alaska C 93160
Dual 800GbE retimer/gearbox with 100G serial I/Os and passive DAC and backplane drive capability
Alaska C 7121P
Dual 400G, quad 200G, octal 100G, 16 port 50G/25G/10G/1G Ethernet transceiver with 256-bit MACsec encryption and Class C PTP timestamping
Alaska C 7120
Dual 400G Ethernet retimer, quad 200G, octal 10G, 16- port 50G/25G PHY/retimer
Alaska C 5243P
Quad 100G, 16- port 25G/10G/1G Ethernet transceiver with 256-bit MACsec encryption and Class C PTP timestamping
Alaska C 5123
Dual- port 100GbE/40GbE, quad port 50GbE, octal port 25GbE/10GbE/1GbE PHY/retimer compliant to IEEE 802.3bj, IEEE 802.3by, IEEE 802.3ba and 25G Ethernet consortium specifications
Alaska C 5121
Dual 100 Gbps Ethernet transceiver with integrated FEC for copper cCable and backplane drive capability
Alaska C 5113
Integrated 40GbE to 25GbE gearbox, quad 25G Ethernet transceiver with copper cable and backplane drive capability
Alaska C 5111
Integrated 100 Gbps Ethernet/MLG gearbox with integrated FEC for copper cable and backplane drive capability
Vega
PAM4 clock and data recovery
As high-speed PAM4 interfaces extend across networking systems, signal degradation can limit reliable connectivity between devices. Clock and data recovery can restore signal quality between high-speed interfaces without requiring a full Ethernet PHY feature set.
The Marvell® Vega PAM4 DSP is an octal-port bidirectional clock and data recovery device designed for high-speed PAM4 connectivity. It provides signal conditioning for applications that require high-speed electrical interface extension between system components.
